SDH/Sonet Radio Features and Applications
|
Pinnacle | - | Frequency Range from 18 through 38 GHz |
| - | OC-3/STM-1 alternative to fiber |
| - | SNMP Management |
| - | Spectrum Efficient Modulation |
| - | Ruggedized weatherproof packaging of the outdoor RF unit |
| - | Upgradeable to higher capacities |
| - | Fast Ethernet Interface Option |
General Description
The Pinnacle Product Family provides a high-capacity point-to-point system for 155Mbps (SDH/SONET) communication for use in Personal Communication Systems, carrier, and wireless broadband access applications. The system includes a low profile outdoor unit (ODU) containing the RF assembly, a high performance antenna and mount, and a 1U advanced digital modem indoor unit (IDU).
The Pinnacle makes extensive use of latest MMIC and VLSI technologies, providing a compact low power consumption terminal providing a high MTBF with low cost of ownership.
Superior technology, market leadership and global presence make the Pinnacle the choice of network operators worldwide. Where time-to-market, cost effectiveness, and system performance are the decision criteria, the only choice is Pinnacle.
